▲ Adopting a nano crystal high-efficiency, environmentally friendly and radiation resistant power supply system, which greatly reduces the harm of ionizing radiation to the human body while improving the efficiency of the power amplifier;

▲ By optimizing the power supply system, the delicacy of mid to high frequency sound and the density of low frequencies are greatly improved, making the vocals more delicate and sweet, and the bass more solid and heavy;

The device is equipped with four sensitivity options to better solve the problem of inconsistent audio signal strength for users, and can achieve the same level of performance regardless of any audio source;

▲ The circuit design of this machine has been optimized, with the maximum sensitivity adjusted to 2.19V to avoid damage to the backend system caused by strong signals such as musical instruments and current noise;

▲ The appearance design is a fully heat dissipating panel, which avoids system protection caused by environmental overheating and maximizes system stability;

8 Ω output power: 1850Wx2

4 Ω output power: 2590Wx2

8 Ω Bridge: 5180W

Limiting protection: up to 10V

Frequency response: 20Hz-20KHz (± 0.3dB)

Input sensitivity: 0.775v/1.4V/26dB;

Total harmonic distortion:<0.05% @ 8 Ω 1KHZ

Signal to noise ratio: ≥ 108dB

Damping coefficient: ≥ 900

Intermodulation distortion: ≤ 0.02%

Installation space: 2U

Chassis size: 485 × 460 × 88mm
