1. The host is equipped with a 1.8-inch TFT display screen, which displays the antenna signal status, microphone receiver online status, and power output status;

2. The panel is equipped with a GAIN gain button, which can adjust the gain by+3dB,+6dB, and+9dB. The screen displays the gain settings;

3. Configurable directional and omnidirectional antennas;

4. Two groups of AB with 8 signal outputs: microphone host antenna reception;

5.1 DC 12V 5A inputs: antenna amplifier host power socket;

6.2 cascaded output interfaces: connect to the next antenna amplifier;

7.4 DC power outputs: DC output DC12V-1A;

8.2 active antenna amplification modules (or passive antennas);

9. Input interface AB: with DC8V 500mA output;

10. Antenna type: Logarithmic Periodic Dipole Array (LPDA) antenna;

11. Connection terminal: fixed right angle BNC female socket;

12. Directional polarity: Vertical (installed vertically);

13. Directionality: Elliptical 180 ° typical;

14. Working frequency band: 500MHz-900MHz;

15. Number of waveguide segments: 11 segments;

16. Voltage standing wave ratio: up to 1.5;

17. Working voltage: 8V DC;

18. Coating: white;

19. Weight: 400 grams;
