On the basis of ensuring low distortion, the receiving distance has been enhanced to meet the long-distance receiving needs of users;

The color of the frequency band values can be autonomously changed by whether the pairing has been completed, visually displaying whether the pairing has been successful. Users can quickly and accurately match the microphone and corresponding host they are currently using;

▲ Two backup channels have been added, with two microphones pre tuned to the same channel. In the event of insufficient or damaged microphone battery, backup microphones can be quickly switched to ensure uninterrupted user use;

At the beginning of the design, a unique anti-interference frequency band automatic search module was added, allowing the device to autonomously search for the frequency band with the strongest anti-interference ability, minimizing interference from other devices on the microphone;

Microphone parameters:

Frequency range: 600-940MHz

Adjustable channel count: 128

Frequency stability: ± 10ppm

Modulation method: FM

RF power: ≤ 50mW

Audio frequency response: 40~18000Hz

Distortion: ≤ 1%

Handheld audio head specification: Dynamic coil heart shaped pointing

Waist pack audio head specification: capacitive type

Battery specification: 2 × 1.5V AA Size

Continuation time: 5-10 hours

Receiver specifications

Frequency range: 600-940MHz

Adjustable channel count: 128+128

Oscillation mode: Phase Locked Loop (PLL) frequency synthesis

Frequency stability: ± 10ppm

Receiving method: Super heterodyne secondary frequency conversion

Receiver sensitivity: -100dBm

Audio frequency response: 40~18000Hz

Distortion: ≤ 1%

Signal to noise ratio: ≥ 100dB

Audio output: (XLR) XLR independent balanced output and a mixed unbalanced output with a Φ 6.35 socket

Power specification: DC12~15V/1000mA

Power consumption: ≤ 8W
