1. One three-dimensional AUX with level control for feedback and the ability to send signals to AUX1;

2. A recording machine with a separation switch for input/output, which distributes signals to the control room and output;

3. Equipped with a high pass filter (low cut), with a cut-off point of 100Hz-18dB/Oct;

4. 2-channel balanced gold-plated XLR+2 6.3mm balanced MIC inputs;

5. Single voice/microphone input channel with gain;

6. Phantom power supply: 48V;

7. Equipped with 8 balanced 6.3mm stereo input channels;

8. Frequency response range: 10Hz -200KHz;

9. Total harmonic distortion:<0.005% @+4 dBu;

10. Noise: -129 dBu

11. Signal amplification: 60 dB@1  kHz；

12. Interference: -90 dB@1  kHz；

13. Equalizer:

◆ High notes:+/-15 dB@12  kHz

Mid range:+/-12 dB@2.5  kHz

◆ Bass:+/-15 dB@80  Hz

14. Maximum output level:+22 dBu;

15. Maximum input level:+30 dBu, Gain @+10 dB;

16. Input impedance: microphone: 2.6K Ω, balanced type; Stereo: 20K Ω, balanced; Auxiliary: 20K Ω, balanced type;

Recording: 24K Ω, balanced type;

17. Output impedance: Main output: 240 Ω, balanced, 120 Ω, unbalanced; Auxiliary: 120 Ω, balanced type; Recording: 1K Ω, balanced type; Earphones: 25 Ω, balanced type;

18. The unique and compact design style, combined with the ultra light plastic shell, is extremely suitable for users of mobile applications;

19. Rotary potentiometer reduces component wear;

20. The output interface is designed as a 6.3mm balanced interface, making it convenient for users to purchase audio cables and connectors on their own;

21. Single voice props equipped with high-efficiency 3-segment EQ;

22. Level indicator: 4-digit LED light;

23. Power supply: 240 VAC, 50 Hz; Small size, light weight, easy to flow and use

24. Physical dimensions (depth x width x height): 252 x 188 x 41mm

25. Net weight: 1.4Kg
