1. Realize lossless transmission of audio signals over long distances through Dante technology, suitable for application in large-scale performances, sports venues, etc;

2. Utilizing Dante's bidirectional transmission characteristics to achieve conference room interoperability, suitable for distributed synchronous meetings in the main and deputy conference rooms of government and enterprise units;

3. Simplify complexity and achieve single point to multi-point transmission; One Ethernet cable replaces all audio cables, reducing wiring workload while ensuring zero sound loss;

4. The lossless audio signal transmission distance exceeds 1000 meters and is anti-interference. The network cable is not affected by ionizing radiation, greatly reducing ionizing noise;

Parameters:

1. Analog input channels: 8 channels;

2. Analog output channels: 8 channels;

3. Equipped with 8 sets of 48V phantom power balanced microphone inputs;

4. Frequency response range: 20Hz~20kHz within 0dB ± 1.5dB;

5. Total harmonic distortion:<0.01% at 0dBu 1kHz;

6. Gain range: 0dBu~50dBu;

7. Signal to noise ratio: 107dB;

8. Maximum input level:+20dBu;

9. Maximum output level:+20dBu;

10. Crosstalk: -88dBu;

11. Microphone input impedance: 6.8k Ω;

12. Output impedance: 240 Ω;

13. Working temperature: 0~40 ℃;

14. Height: 2U;

15. Dimensions (width * depth * height): 483mm * 284mm * 88mm

16. Net weight: 4Kg
